This demonstrates the accuracy of the gridding methods and groundwater modeling that you use.Īdding multiple map layers to your map gives you a way to combine different types of data in one map. Post your sample locations, well locations, or original data point locations on a contour map to show the distribution of data points on the map. Also create classed post maps that identify different ranges of data by automatically assigning a different symbol or color to each data range. For each posted point, specify the symbol and label type, size, and angle. Post maps show XY locations with fixed size symbols or proportionally scaled symbols of any color.Ĭreate post maps independent of other maps on the page, or combined with other map layers.
Overlay several surface maps to generate informative block diagrams. Change the lighting, display angle and tilt with a click of the mouse. The 3D surface mapping uses shading and color to emphasize your data features. You can cut, copy, and paste data within the Surfer 12 worksheet or between applications. Data files can be up to one billion rows and columns, subject to available memory. Surfer includes a full-featured worksheet for creating, opening, editing, and saving data files. Your data interpolation (eg.Kriging) can now be fully manipulated.
Drawing 3d cross secrtion with surfer 12 software#
Surfer 12 Software lets you massage your data in many ways to achieve the exact output you want. Surfer uses a variogram grid as a fundamental internal data representation and once this grid is built, any experimental variogram can be computed instantaneously. Variograms may be used to select an appropriate variogram model when gridding with the Kriging algorithm. Use the variogram modeling subsystem to quantitatively assess the spatial continuity of data or data interpolation (eg.Kriging). Reshape the line on the map, and the profile automatically updates. In all cases, the profile is created showing the Z value change along the length of the line. Include as many points as you want in the line it could be a simple two-point line, or a zig-zag shape. Simply select the map, add a profile, and draw the line on the map. Surfer's automatic profile tool makes it easy to visualize the change in Z value from one point to another. The two components of the vector mapping, direction and magnitude, are automatically generated from a single grid by computing the gradient of the represented surface. You can perform vector mapping from information in one grid or two separate grids. Instantly create vector maps in Surfer 12 Software to show direction and magnitude of data at points on a map. It is easy to overlay a base map on a contour or surface wireframe map, allowing you to diversify your mapping and display geographic information in combination with the three dimensional data. You can load any number of base maps on a page for optimum manipulation of your data interpolation (eg. You can combine base maps with other maps in map overlays, or can create stand-alone base maps independent of other maps on the page. Surfer 12 Software can import maps in many different formats to display geographic information, including groundwater modeling. This process transforms your data interpolation (eg.kriging) into brilliantly colored models. And with Surfer 12 software's easy map contouring you can add color fill between contours to produce dazzling displays of your maps or groundwater modeling, or produce gray scale fills for dramatic black and white printouts. With help from and Golden Software's Surfer 12 software generating publication quality maps has never been quicker or easier.ĭisplay contour maps over any contour range and contour interval, or specify only the contour levels you want to display on the map. Virtually all aspects of your maps can be customized to produce exactly the presentation you want. Add base maps and combine map types to create the most informative display possible. Display your grid as outstanding contour, 3D surface, 3D wireframe, watershed, vector, image, shaded relief, and post maps. You can also use grid files obtained from other sources, such as USGS DEM files or ESRI grid files. Surfer provides more gridding methods and more control over gridding parameters, including customized variograms, than any other software package on the market. kriging) engine transforms your XYZ data into publication-quality maps.
